What Are CBB Series Film Capacitors Used For in Motor Run and HVAC Applications?

Introduction

Film capacitors play a critical role in modern motor-driven systems, especially in HVAC equipment, compressors, fans, and pumps. Among them, CBB series film capacitors are widely used as motor run capacitors due to their stable electrical performance and long service life.

In this article, we explain what CBB series film capacitors are, how they work, and why they are commonly used in motor run and HVAC applications.

What Is a CBB Series Film Capacitor?

A CBB series capacitor is a type of metallized polypropylene (MPP) film capacitor designed for AC applications. It is commonly used as a motor run capacitor, providing continuous phase shift and improving motor efficiency during operation.

Typical CBB series products include:

• CBB60 – Used in air conditioners and compressors

• CBB61 – Common in fans and small motors

• CBB65 – Designed for higher capacitance motor run applications

These capacitors are known for low loss, stable capacitance, and high insulation resistance.

Why Metallized Polypropylene Film Is Used

Compared with other dielectric materials, metallized polypropylene film offers several advantages:

• Low dielectric loss

• Excellent temperature stability

• High voltage withstand capability

• Long operational lifetime

Because of these characteristics, MPP film capacitors are suitable for continuous-duty motor run applications, where reliability is critical.

Applications of CBB Film Capacitors

CBB series film capacitors are widely used in:

• HVAC systems

• Air conditioner outdoor and indoor units

• Electric fans

• Water pumps

• Compressors

• Industrial motor equipment

In these applications, the capacitor helps improve motor starting performance, running efficiency, and overall system stability.

Manufacturing Process and Quality Control

At EVA Comp, CBB film capacitors are produced through a controlled manufacturing process that includes:

• Film winding

• Welding and lead assembly

• Resin filling or sealing

• Electrical testing and final inspection

Each production step is designed to ensure consistent performance and compliance with international standards.

Customization and OEM Support

Different motor applications require different capacitance values, voltage ratings, and case sizes. EVA Comp supports OEM and customized capacitor solutions, helping customers select suitable specifications based on their application requirements.

Conclusion

CBB series film capacitors are an essential component in motor run and HVAC applications, offering stable performance and long-term reliability. Choosing the right capacitor and a reliable manufacturer is key to ensuring product quality and system safety.

If you are looking for a film capacitor manufacturer or need support with motor run capacitor selection, EVA Comp is ready to assist.
