MKP X2 capacitors are designed for high-fidelity audio circuits, providing precise AC signal filtering, low distortion, and reliable EMI suppression for professional and consumer audio equipment.
Model Number :
MKP X2Brand Name :
EVAShape :
RectangularTerminal :
CP WiresProtection Class :
S0,S3Color :
Yellow,Blue,Grey,etcWarranty :
3 years or 5 yearsOperation Temperature :
40/105/21/COrder(MOQ) :
50Product Origin :
Anhui,ChinaPayment :
T/T,L/C,DPLead Time :
7-15 DaysShipping Port :
Shanghai,Ningbo,Qingdao,Guangzhou,Yiwu,etcThe MKP X2 capacitor is a metallized polypropylene capacitor optimized for audio signal circuits.
It ensures clean signal transmission, reduces high-frequency noise, and maintains consistent performance in amplifiers, mixers, and other high-end audio devices.
Key Features
Optimized for audio signal circuits and AC filtering
Low ESR and low dielectric loss for minimal signal distortion
EMI suppression to protect sensitive audio components
X2 safety certified for voltage spikes and transient suppression
Stable performance across wide temperature ranges typical for audio environments
Technical Parameter：
Dielectric: Metallized Polypropylene Film
Circuit Type: AC Signal / Audio Filtering
Capacitance Range: Tuned for audio applications
Rated Voltage: AC line filtering and signal path protection
Safety Standard: X2 certified
Operating Temperature: -40°C to +105°C
| Subclass | X2 | |
| Rated voltage | 250/275/310VAC (50/60Hz) | |
| Capacitance range | 0.22μF～3.3μF | |
| Capacitance tolerance | ±5% (J), ±10% (K) | |
| Voltage proof | between terminals | 4.3*UR (VDC) / 10s |
| between terminals and case | 2*UR+1500 (VAC) / 60s(2000VAC min) | |
| Insulation resistance (20℃) | between terminals | ≥15000MΩ, CR≤0.33μF(100VDC,60s) |
| between terminals and case | ≥5000S, CR＞0.33μF (100VDC, 60s) | |
| Tangent of loss angle (20℃) | CR≤1μF | ≤0.001 (1KHz); ≤0.003 (10KHz) |
| CR＞1μF | ≤0.002 (1KHz) | |
| Pulse rise time(dv/dt) | 100V/ μs Max | |
Typical Applications:
🎵 Audio Systems
Ideal for professional and consumer audio equipment, including:
Audio amplifiers and preamplifiers
Mixers and signal processing units
Hi-Fi speaker crossovers
EMI suppression in AC input circuits
⭐ Product Advantage
Reduces signal distortion in audio circuits
Suppresses EMI for clean sound reproduction
Provides high reliability in continuous operation
Long service life for professional audio equipment
OEM-friendly for audio device manufacturers
Why Choose Our Capacitors
*Over 17 years of manufacturing experience in motor capacitors
*Strict process control from winding to final electrical testing
*Stable long-term supply for OEM and bulk orders
*Custom capacitance, voltage, and lead configuration available
How To Order
Our Certificate
Our Exhibition
Our Packing
Packing
Our standard packaging follows a double-protection structure of inner box + Outer carton, ensuring your products arrive safely and in perfect condition. For certain items, we also offer individual packaging options, which can be fully customlized according to your requirements.
All outer cartons are made from export-grade, 5-ply corrugated material, providing exceptional strength, compression resistance, and durability during long-distance transportation. We strictly follow international packaging standards to guarantee secure delivery—whether by sea, air, or express.
Customlized packaging, labeling, and palletizing can also be arranged to meet your specific logistics or branding needs.
Logistics & Payment
🚢 Shipping Methods
We provide multiple shipping solutions to meet different delivery needs:
Sea Freight — stable and cost-effective
Air Freight — fast and suitable for urgent or small-volume shipments
We will recommend the best shipping method based on your order size, delivery schedule, and budget.
FAQ
1. Q:What is the principle of explosion-proof safety film capacitor?
A:The metallized electrodes adopt tiny fuses structure. If there is any failure during capacitor operation, the power supply is automatically cut off by disconnecting the micro-fuse. In this way, the failure can be prevented and self-safety protection realized.
2. Q:What’s meaning of P0(S0) and P2(S3) in the EVA capacitor?
A:P0(S0) and P2(S3) are refer to the class of safety protection. P0(S0) means non-explosion-proof. P2(S3) means explosion-proof.
3. Q:Common Installation Methods of Fan Capacitor
A:According to customers’ different installation methods on products, EVA-capacitor can provide the following capacitor styles. EVA-ac motor capacitors are used for starting, running and adjusting speed. EVA-Capacitor are widely applied in table tans, floor fans, ceiling fans, wall fans, luxury ceiling fans, exhaust fans, extractor fans, heater, smash paper machine, turbine, dehumidifier, etc.
Noted: Since the capacitor is made of plastic material, improper installation of the capacitor can cause the plastic ear to break. Therefore, the customer should pay attention to the URYU, screw, hole position to maintain vertical state during the fan capacitor installation.
4. What capacitance tolerances are available?
A:Tolerance on rated capacitance determines its application. Common values are ±5%（J）,±10%（K0）, ±20%（M）.
